Z Subwoofer

I subwoofer della serie Z offrono maggiori performances grazie all’utilizzo di trasduttori più piccoli in quantità maggiori.
Applicazioni: locali di musica live, piano bar, discoteche, sale concerti

Richiedi Informazioni

La Serie Z Subwoofer

ZW 208

Dispersion OMNI
Transducers 2 x 8’’ (2,5 V.C.)
Impedance 8Ω
Rated Power 500W
Peak Power 2000W
Sensitivity 1W/1m 95 dB Spl
SPL cont/peak 1m 122/128 dB Spl
Freq. range (-10dB) 48Hz
Dimension (mm) H 510 x W 300 x D 450
Weight (kg) 15

Preset

DWG

Users Guide

ZW 210

Dispersion OMNI
Transducers 2 x 10’’ (3″ V.C.)
Impedance 8Ω
Rated Power 1000W
Peak Power 4000W
Sensitivity 1W/1m 97 dB Spl
SPL cont/peak 1m 127/133 dB Spl
Freq. range (-10dB) 34Hz
Dimension (mm) H 600 x W 400 x D 550
Weight (kg) 29

Preset

DWG

Users Guide

ZW 408

Dispersion OMNI
Transducers 4 x 8” (2,5” V.C)
Impedance 8Ω
Rated Power 1000W
Peak Power 4000W
Sensitivity 1W/1m 98 dB Spl
SPL cont/peak 1m 128/134 dB Spl
Freq. range (-10dB) 35Hz
Dimension (mm) W 400 x H 800 x D 550
Weight (kg) 35

Preset

DWG

Users Guide

ZW 410 H

Dispersion OMNI
Transducers 4 X 10” (3” V.C.)
Impedance 8Ω
Rated Power 2000W
Peak Power 8000W
Sensitivity 1W/1m 104 dB Spl
SPL cont/peak 1m 136/142 dB Spl
Freq. range (-10dB) 43Hz
Dimension (mm) W 800 x H 617 x D 656
Weight (kg) 62

Preset

DWG

Users Guide

ZW 810 I

Dispersion OMNI
Transducers 8 X 10” (3” V.C.)
Impedance 4Ω + 4Ω
Rated Power 2000W + 2000W
Peak Power 8000W + 8000W
Sensitivity 1W/1m 103 dB Spl
SPL cont/peak 1m 139/145 dB Spl
Freq. range (-10dB) 24Hz
Dimension (mm) W 1200 x H 620 x D 750
Weight (kg) 140

Preset

DWG

Users Guide
